The Hollyland Mars 4K Wireless Video Transmitter adds up to 4K30 wireless video transmission to your gimbal, mirrorless, or DSLR camera rig. Key features include:

  • Smart channel scanning

  • Transmit up to UHD 4K30 Video up to 450-feet

  • Touchscreen LCD

  • SDI & HDMI inputs

Radio, Live Transmission. With the Hollyland Mars 4K Wireless Video Transmitter, any discerning videographer looking for high-resolution production capability will find what they’re looking for. This transmitter supports FHD and HD formats at varying frame rates such as 24, 30, and 60p.

Designed For Durability & Accessibility. The Mars 4k offers corrosion & wear resistant capabilities, making user experience a little less stressful to navigate. The design form factor optimizes operational functionality for fast configurations with wiggle-free, bullet-styled antennas attached. The included touchscreen LCD allows you to configure any settings or status checks at a rapid pace, and additionally includes a gamepad-style button that dramatically improves the operational setup experience.

Smart Channel Scanning & Power Options. An intelligent channel scan helps determine which channels are open & closed for use, allowing interference-free transmission. A stable connection is very possible automatically upon startup! This transmitter is fueled by a few different options: 6 to 16 VDC coax input, L-series/NP-F batteries, or USB-C chargers.

Hollyview App. Whether you’re team iOS or team Android, you can easily download the Hollyview app to monitor your transmission on a smartphone or tablet. It allows you to transmit to apps and receivers in the following configurations:

  • Transmitter to 1 receiver + 2 apps
  • Transmitter to 4 apps
  • Mars M1 wireless transceiver monitor to 1 receiver and 2 apps

Q & A

  • Does this rental only include the transmitter?
    • Yep! If you’re lookin for a whole setup, clicky here.

  • Does the transmitter cross convert between HDMI and SDI?
    • Yes, both the RX and TX units of the Hollyland Mars 4K Wireless Video Transmission System have cross-conversion, so operators could have an HDMI source coming in and an SDI source going out on the TX unit for example.

  • How many receivers can be used with one transmitter?
    • The Mars 4K supports 1 transmitter to 2 receivers.

  • Resources

  • Manual
  • HollyView App (iOS)
  • HollyView App (Android)
  • Brand

    Hollyland

    Environmental

    IP Rating

    • None
    Operating Temperature
    • 14 to 140°F
    Storage Temperature
    • -40 to 140°F



    Format Support

    Video Format
    HDMI

    • UHD 4K: 30
    • 1080p: 60/30/24
    SDI
    • 1080p: 60/59.94/30/29.97/24/23.98
    Timecode Support
    • Yes



    Inputs/Outputs Antenna Ports
    • 2 x RP-SMA Male
    Video I/O
    • 1 x HDMI Input
    • 1 x BNC Input
    Embedded Audio
    • HDMI/SDI
    Audio I/O
    • None
    Power I/O
    • 1 x Barrel Input
    • 1 x USB-C Input
    Item Type

    Monitoring

    Monitoring Type

    Wireless

    Mounting

    1 × 1/4"-20 Female

    Physical Dimensions
    • 4.5 × 2.6 × 1.3″
    Weight
    • 7.9 oz Excluding Antenna
    Power

    DC Input Power

    • 6 to 16 VDC
    Power Consumption
    • 8.5 W



    Wireless Wireless Range
    • 450’ (Line-of-Sight)
    Channel Bandwidth
    • 20 MHz
    Frequency Range
    • US: 5.1 to 5.8 GHz
    Latency
    • 66 ms
    RF Power
    • 21 dBm
    Wi-Fi
    • Wi-Fi 4 (802.11n)
    App Compatible
    • Yes
