The RED SCARLET-W Digital Cinema Camera brings RED's famous DRAGON sensor to a smaller and more modular body. REDCODE RAW formats give you tons of editing options as well as recording formats that range from 5K 2.4:1 at 60 fps, 4K 2.4:1 at 150 fps, or 2K 2.4:1 at 300 fps!!! 3D LUTs and an intelligent OLPF system round out the Scarlet-W's features. We include 2x BlueShape BV095 Mini V-Mount batteries, each last about 90 minutes. Our kit includes 3x OLPFs, Standard, Low Light Optimized, & Skin Tone Highlight. We also include 1x 120GB Red Mini Mag SSD. You can rent additional Mini Mags here.

SENSOR

SENSOR TYPE RED DRAGON 13.8 MP Super 35 mm CMOS
EFFECTIVE PIXELS 5120 x 2700
SENSOR SIZE 25.6 mm x 13.5 mm (Diagonal: 28.9 mm)
DYNAMIC RANGE 16.5+ stops
SIGNAL-TO-NOISE-RATIO 80 dB



RECORDING

MAX DATA RATES Up to 140 MB/s using RED MINI-MAG
MAX FRAME RATES 1 50 fps at 5K Full Frame (5120 x 2700), 60 fps at 5K 2.4:1 (5120 x 2160)
120 fps at 4K Full Frame (4096 x 2160), 150 fps at 4K 2.4:1 (4096 x 1728)
150 fps at 3K Full Frame (3072 x 1620), 200 fps at 3K 2.4:1 (3072 x 1296)
240 fps at 2K Full Frame (2048 x 1080), 300 fps at 2K 2.4:1 (2048 x 864)
PLAYBACK FRAME RATES
(PROJECT TIMEBASE)
23.98, 24, 25, 29.97, 47.95, 48, 50, 59.94, 60 fps, all resolutions
REDCODE SETTINGS
RANGE FROM 2:1 UP TO 22:1 1
5:1 REDCODE for 5K Full Frame (5120 x 2700) at 24 fps
9:1 REDCODE for 5K Full Frame (5120 x 2700) at 50 fps
3:1 REDCODE for 4K Full Frame (4096 x 2160) at 24 fps
7:1 REDCODE for 4K Full Frame (4096 x 2160) at 60 fps
REDCODE RAW
ACQUISITION FORMATS 2
5K Full Frame (5120 x 2700), 2:1, 2.4:1, 16:9, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
4K Full Frame (4096 x 2160), 2:1, 2.4:1, 16:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
3K Full Frame (3072 x 1620), 2:1, 2.4:1, 16:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
2K Full Frame (2048 x 1080), 2:1, 2.4:1, 16:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
APPLE PRORES 422 HQ, 422 and 422 LT at 2K (2048 × 1080) up to 60 fps
AVID CODECS 3 DNxHD HQ, SQ and LB (1920 × 1080) 8-bit up to 60 fps
TYPICAL MAX RECORDING TIME
USING RED MINI-MAG 120GB 5
5K Full Frame (5120 x 2700) at 24 fps and 11:1 REDCODE: 41 minutes
5K Full Frame (5120 x 2700) at 48 fps and 14:1 REDCODE: 26 minutes
4.5K 2.4:1 (4608 x 1944) at 120 fps and 15:1 REDCODE: 17 minutes



GENERAL

CONSTRUCTION Aluminum Alloy
WEIGHT 3.5 lbs (BRAIN with Integrated Media Bay)
OPERATING TEMPERATURE 0°C to 40°C (32°F to 104°F)
STORAGE TEMPERATURE –20°C to 50°C (–4°F to 122°F)
RELATIVE HUMIDITY 0% to 85% non-condensing



FEATURES

COLOR MANAGEMENT Supports 17×17×17 3D LUTs
Variable number of 3D LUT outputs with DSMC2 expander module
User programmable shaper 1D LUTs
Tetrahedral interpolation, 16-bit processing
AUDIO Integrated dual channel digital stereo microphones, uncompressed, 24-bit 48 kHz
Optional 2 additional channels with DSMC2 expander module, uncompressed, 24-bit 48 kHz
REMOTE CONTROL Integrated REDLINK WiFi antenna
Ethernet, RS232, and GPI Trigger with DSMC2 expander module
MONITOR OUTPUTS 3G-SDI (HD-SDI) and HDMI with DSMC2 expander module
1080p RGB or 4:2:2, 720p RGB or 4:2:2
480p RGB or 4:2:2 (HDMI Only)
SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio
MONITOR OPTIONS DSMC2 RED Touch 4.7" LCD, DSMC2 RED Touch 7.0" LCD and DSMC2 RED EVF (OLED) with cable-free connection.
RED Touch 9.0" LCD, RED Touch 7.0" LCD, RED Touch 5.0" LCD, RED PRO 7" LCD, BOMB EVF (OLED) and BOMB EVF (LCOS) compatible with DSMC2 LEMO Adaptor A and LCD/EVF cable.



SOFTWARE

REDCINE-X PRO
DELIVERY FORMATS
4K: DPX, TIFF, OpenEXR (.RED via RRencode plugin)
2K: DPX, TIFF, OpenEXR (.RED via RRencode plugin)
1080p RGB 4:2:2, 720p 4:2:2 : QuickTime, JPEG, AVID AAF, MXF
1080p 4:2:0, 720p 4:2:0 : H.264, .MP4
VIDEO EDITING SOFTWARE
COMPATIBILITY 4
Adobe Premiere Pro, Avid Media Composer
DaVinci Resolve, Edius Pro, Final Cut Pro, Vegas Pro

RED DSMC2 4.7" Touch LCD

RED DSMC2 Universal Handle

RED DSMC2 AC Adapter

RED Station Mini Mag USB 3.0 Reader

RED 120GB Mini Mag

Red USB 3.0 SS USB Cable

RED Mini Mag Reader USB Barrel Power Cable

RED DSMC2 Low Light OLPF

RED DSMC2 Skin Tone OLPF

RED DSMC2 Standard OLPF

RED Sidewinder Multi-Tool with Case

USB Wall Charger

BlueShape BV095 Granite Mini V-Mount Battery

BlueShape BV095 Granite Mini V-Mount Battery

BlueShape CVTR1M Battery Charger

BlueShape CVTR1M Battery Charger

Universal Power Cable

Universal Power Cable

Universal Power Cable

RED EF Body Cap

Wooden Camera Easy Riser Plate for RED

RED DSMC2 Side Handle
